Qoltec 12 x Pigtail fiber optic LC/APC | Singlemode | G657A2 | 2m
Qoltec Pigtail fiber optic SC/APC | Singlemode | 9/125 | G657A2 | 3m
Qoltec Pigtail fiber optic SC / UPC | Singlemode | 9/125 | G657A | 1m
Product code: 54428
Single-mode optical pigtail
Connectors: SC / UPC
Standard: G657A
Cable diameter: 0.9 mm
Cable length: 2 m
CONFIDENCE CONFIRMED BY A WARRANTY
Do you want a high quality product? Our solutions will meet your expectations. Fiber optic pigtails offered by us are covered by a 24-month guarantee valid from the date of purchase.
Technical data
Producer
Qoltec
Type pigtail
Singlemode
Type connectors
SC/UPC
Standard fiber
G657A2
Fiber core diameter
9/125 µm
Sheath
LSZH
Diameter cable
0.9 mm
Insertion loss
<0.3 dB
Return loss
>55 dB
Cable length
1 m
Colour
Blue, white
Additional information
Easy installation and operation of optical fiber, high data transmission speed.
LSZH - non-flammable outer cable sheath that does not emit harmful gases during a fire.
The product is individually tested.
LSZH - non-flammable outer cable sheath that does not emit harmful gases during a fire.
The product is individually tested.
Package depth / length [mm]
140
Package width [mm]
150
Package height [mm]
10
Package
Polybag
Net weight [kg]
0.0030
Gross weight [kg]
0.0080
Warranty
24 months
EAN code
5901878544281
